By NavCom

John Deere SF-5050 StarFire GNSS Receiver P/N NASF5050WUB750516

$2,000.00 USD
$2,000.00 USD
Availability: Low stock: 1 left
SKU: SF-3050
44623936
$2,000.00 USD
$2,000.00 USD

Brand: NavCom

MPN: SF-3050

UPC: Does not apply

Used, pulled out of a working environment.  Will come exactly as pictured.  Very rare and hard to find part.

The SF-5050 is fully upgradeable allowing users to upgrade from an autonomous receiver to a variety of augmentation capabilities with just a software bundle upload. This flexible framework makes the SF-5050 ideal for any application.

The SF-5050 replaces the SF-3050 StarFire GNSS Receiver.

FEATURES

All-in-view parallel tracking with 255 channels

SBAS (WAAS/EGNOS/MSAS/GAGAN) tracking

Built-in 3-channel StarFire receiver and demodulator:

  • GPS: L1 CA, P1,L2 L2CA, P2, L2CL, L5 L5Q
  • GLONASS: G1 G1C, G2 G2C
  • Beidou: B1 B1l, B2 B2I
  • Galileo: E1 E1B, E5A E5AQ, E5B E5BQ

High sensitivity / low signal level tracking

Fast acquisition / re-acquisition

Superior interference suppression (both in-band & out-of-band)

Patented multipath rejection

StarFire Over IP delivery (Optional)

RTK ExtendTM

Over-the-air StarFireTM licensing option

Minimal data latency

Data message formats:

  • NMEA-0183: ALM, DTM, GBS, GFA, GGA, GLL, GNS, GRS, GSA, GST, GSV, HDT, MLA, RMC, RRE, ROT, TTM, VTG, ZDA, PNCT, NCT proprietary
  • Differential Correction: SBAS and StarFire (proprietary)
  • RTK Correction: RTCM 2.3, 3.0, and MSM, NavCom Proprietary UltraRTKTM
  • Receiver Control: NavCom proprietary commands
Configurable as RTK base or rover

Programmable output rates

Event marker input

1 PPS output

Communication Ports: 4 x RS232 (2 – Changeable to RS422) ; 2 x USB 2.0 (Device); Ethernet (10T/100T)
