Brand: Tesla
Voltage: 230v Single phase
Color: Silver
Number of Phases: 1
Connector Type: NACS
Amperage: 32a
Manufacturer Part Number: 1050067-01-H
Model: 1050068-01-H
Level: 2
Material: Plastic
Country of Origin: United States
Charging Rate: 7.4kw
UPC: N/A
For the fastest home charging, install Wall Connector with a circuit breaker that matches your vehicle’s onboard charger capabilities. To view the max amperage of your Tesla vehicle, tap the lightning bolt icon on the touchscreen. To determine the max amperage of your electric vehicle, refer to your vehicle manufacturer’s guidance.
For unique power situations or when power may be limited, Wall Connector can also be installed with lower amperage circuit breakers to support almost any existing electrical system.
Refer to the following table for Tesla vehicle charging speeds for each power level option:
| Vehicle | Max Charge Power Based on Vehicle Capabilities and Wall Connector Current Settings | ||
|---|---|---|---|
| Model S, Model 3, Model X, Model Y, Cybertruck |
230 V Single-phase: 7.4 kW (32 A) |
230 V Three-phase delta: 11 kW (28 A) |
400 V Three-phase wye: 11 kW (16 A) |
